Mechanical Properties
MXD6-CF40 is a high performance polyamide based composite reinforced with 40% carbon fiber, providing maximum stiffness, strength, and wear resistance compared to unreinforced MXD6 and lower CF content variants. The higher carbon fiber content significantly enhances dimensional stability and mechanical durability, making it suitable for structural and high performance applications.
Tensile Strength: ≥ 220 MPa
Flexural Strength: ≥ 310 MPa
Impact Strength: ≥ 5.5 kJ/m²
With 40% carbon fiber reinforcement, MXD6-CF40 offers superior mechanical strength, extreme stiffness, and excellent wear resistance, making it an ideal choice for the most demanding applications.
Thermal and Chemical Resistance
MXD6-CF40 retains the exceptional thermal stability and chemical resistance of MXD6 while benefiting from the enhanced heat resistance and rigidity of carbon fiber reinforcement.
Heat Deflection Temperature (HDT): Approx. 320°C
Long-Term Service Temperature: Up to 320°C
Chemical Resistance: Excellent resistance to oils, fuels, solvents, and various industrial chemicals
MXD6-CF40 ensures long term reliability in high temperature and chemically aggressive environments.
Wear Resistance and Processing
With 40% carbon fiber content, MXD6-CF40 offers exceptional wear resistance and significantly reduced friction, making it ideal for applications exposed to extreme mechanical stress and frictional forces.
Wear Resistance: Outstanding in high wear and friction conditions
Processing Methods: Injection molding, extrusion (reinforced tooling required)
Due to the higher carbon fiber content, MXD6-CF40 requires reinforced molds and optimized processing parameters to ensure efficient manufacturing and the best mechanical performance.
Environmental Adaptability
MXD6-CF40 features very low moisture absorption and exceptional dimensional stability, ensuring consistent performance under extreme environmental conditions.
Water Absorption: Minimal, preventing swelling and material degradation in humid environments
Dimensional Stability: Outstanding, with negligible expansion or contraction under temperature or humidity changes
Applications
MXD6-CF40 is a high strength, carbon fiber reinforced polyamide designed for applications demanding extreme mechanical strength, dimensional stability, and chemical resistance. Its low moisture absorption and enhanced wear resistance make it ideal for harsh operating environments requiring long term durability and mechanical reliability.
Automotive
MXD6-CF40 is widely used in the automotive industry, where ultra lightweight, high strength materials contribute to fuel efficiency and structural integrity. Its exceptional heat resistance and rigidity make it ideal for:
Structural components that require maximum mechanical strength and load bearing capacity
Brackets and supports exposed to extreme stress and high temperatures
Lightweight reinforcements replacing metal components to reduce weight
Under-the-hood components, such as housings and connectors, that must withstand high heat and chemical exposure
Summary Table for MXD6-CF40
Characteristic |
Value/Description |
Carbon Fiber Content |
40% |
Tensile Strength |
≥ 220 MPa |
Flexural Strength |
≥ 310 MPa |
Impact Strength |
≥ 5.5 kJ/m² |
Heat Deflection Temp. |
Approx. 320°C |
Long-Term Service Temp. |
Up to 320°C |
Chemical Resistance |
Excellent |
Water Absorption |
Very low |
Processing Methods |
Injection molding, extrusion (reinforced tooling required) |
Wear Resistance |
Outstanding in high wear conditions |
If you want to get more information about MXD6-CF40, you can visit our Youtube.
